SIEMENS ‘SIEPAN 8PU’ PANELS
Siemens 8PU design for low voltage switchboards has become an industry benchmark with proven performance for the past many decades.
Designed to operate in challenging conditions of high ambient & dust 8PU low voltage switchboards have been patronized by various segments like cement, steel, refinery, oil & gas, pharma, F&B, data centres, hospitals & hotels, metro-rail projects having deployed more than 100,000 LV switchboards for maximum reliability and performance.
This proven technology from Siemens for SIEPAN 8PU® LV Switchboards is now also available through a network of Licensed Partners across the country.
Customer benefits at a glance
⇒ Siemens innovation & technology
⇒ Maximum reliability in protection of your plant and equipment
⇒ Maximum safety for operating personnel.
⇒ Suited for the most arduous site conditions.
⇒ Siemens innovation & technology.
⇒ Extensive License Partner network across the country
Highlights
⇒ Conformance to Type Tested assemblies (TTA)
⇒ Conformance to Seismic withstand upto Zone V
⇒ Conformance to Internal Arc Containment (IAC)
⇒ Fully compartmentalized, bolted & modular design for PCC & MCC
⇒ Non-compartmentalized drive control panels
⇒ Non-compartmentalized APFC panels
Range
⇒ Power control centres
⇒ Communication capable intelligent power control centres (IPCCs)
⇒ Withdrawable motor control centres with patented Alstan® bus-bar technology
⇒ Energy management PCCs for Plant & Building
⇒ Motor control centres – Fuseless and with Fuse
⇒ Intelligent motor control centres (IMCCs)
⇒ Integrated PMCCs for Ethernet connectivity
⇒ Automatic power factor correction panels
⇒ All variants available with a choice of aluminum and copper for bus-bars
⇒ Degree of ingress protection upto IP 54 for all ratings
LV switchboard SIEPAN 8PU:
Technical Data
| Conformance to standards | IS /IEC 61439- 1&2 |
| Internal Arc Containment | IEC 61641 |
| Seismic withstand | IS 1893 |
| Short circuit withstand (Icw) - main bus | 65kA / 1sec / 143kA peak |
| Short circuit withstand (Icw) - neutral | 39kA / 1sec / 82kA peak |
| Short circuit withstand (Icw) - earth | 39kA / 1sec / 82kA peak |
| Degree of protection (IP) | IP 4X, 5X, X3, X4 |
| Ambient temperature | 40º C / 45º C / 50º C |
| Temperature rise | As per IEC 61439 -2 |
| Seismic conformance test | Zone III & V |
| Rated insulation voltage | upto 1000V |
| Rated operational voltage | upto 690V |
| Rated impulse withstand | 8kV |
| Main busbar rating | upto 5000A |
| Busbar execution | Interleaved / non-Interleaved |
| Busbar options | Copper / aluminium |
| lnfeed termination | Cable / bus ways / busduct |
| lnfeed entry | Top / bottom |
| Cable feeder access | Front / rear* |
| ACB cubicle | Single tier |
| Form of seperation | upto form 4B |
| Standard height | 2300mm |
| Standard depth | 1120mm / 560mm |
| Standard colour shade | RAL 7035 / RAL 7032 |
